Monsun® 21 Eco, ON/OFF Multilumen, PMMA
Schließen
Article damp-proof luminaire
Product name Monsun® 21 Eco
Lamp LED
Rated luminous flux 7000lm
Luminous efficacy 140lm/W
Colour temperature 4000K
Colour rendering CRI > 80
Rated input power 50W
Service life 50000h (L80/B50) at AT = 25°C
Protection rating IP66
Impact resistance IK02
Weight 2.1kg
Monsun® 21 Eco, damp-proof luminaire, primary optical cover: diffuser, of PMMA, frosted, light emission: direct distribution, primary light characteristic: symmetric, installation type: suspended mounting, surface-mounted, LED, rated luminous flux: 7.000lm, luminous efficacy: 140lm/W, light colour: 840, colour temperature: 4000K, control gear: ON/OFF Multilumen, with terminal, 3-pole, max. 2.5mm², mains connection: 220..240V, AC, 50/60Hz, rated input power: 50W, housing, of glass-fibre reinforced polyester, light grey (RAL 7035), length: 1.577mm, width: 90mm, height: 95mm, clip for enclosure, of spring steel V2A, protection rating (complete): IP66, insulation class (complete): insulation class I (protective earthing), certification: CE, UKCA, protection symbol: D, impact resistance: IK02, permissible operating ambient temperature: -20..+35°C, corresponds to IFS (International Featured Standards) requirements for safety and quality in the food industry, contact your sales advisor before using the luminaires in applications with unclear chemical exposure, large temperature fluctuations or condensation-forming humidity, packaging unit: 1 piece
Downloads
Technische Produktinformationen
Daten für Anwendungsprogramme
Produktdetails
Lichttechnischer Prüfbefund / Planungsdaten
Monsun® 21 Eco
LED, ECG Multilumen, diffuser, suspended mounting, surface-mounted, L= 1577mm
Lamps: 1x LED
Bestellnr.: 51FJ10MP47A
