SITECO Connect Wireless, Smart Plug LoRaWAN

Close
Order No.: 5EA3NAS02
Remember articleRemember article

Article sensor
Product name SITECO Connect Wireless
Protection rating IP66
Weight 0.1kg

SITECO Connect WirelessSmart Plug LoRaWAN, sensor, radio, communication: D4i, LoRaWAN, control: remote setup and operation, Smart Interface below and above, The LoRaWAN keys are transmitted as a file, installation type: screw fastening, installation location: to the luminaire, of ABS, voltage: 12..20V, voltage type: DC, protection rating (complete): IP66, certification: CE, packaging unit: set of 36

Downloads

Technical product information
Data for applications

Product details

Key data

Product type sensor
Product name SITECO Connect Wireless
Order No. 5EA3NAS02

Control

Certificates, Standards

Protection rating IP66
Temperature range (operation) -30..+60°C
Standard according to Zhaga book 18
Certification, designation CE

Material, Colour

housing ABS, grey
Colour specification grey

Mounting

Mounting method, mounting location screw fastening, to the luminaire

Electrical connection

Nominal voltage 12..20V, DC

Dimensions, Weight

Weight 0.1kg

Product type
sensor

Product name
SITECO Connect Wireless

Order No.
5EA3NAS02

Protection rating
IP66

Temperature range (operation)
-30..+60°C

Standard
according to Zhaga book 18

Certification, designation
CE

housing
ABS, grey

Colour specification
grey

Mounting method, mounting location
screw fastening, to the luminaire

Nominal voltage
12..20V, DC

Weight
0.1kg
